Cable Drum

YHDC-027

MAX. door height,  3000mm
max,cable diam.,  3.2mm
max,door weight,  240kg
diam. shaft,  25.4mm
disrance up to shaft.45mm



YHDC-028

MAX. door height,  2438mm
max,cable diam.,  3.2mm
max,door weight,  240kg
diam. shaft,  25.4mm
disrance up to shaft.86mm



YHDC-029

MAX. door height,  3352mm
max,cable diam.,  3.2mm
max,door weight,  454kg
diam. shaft,  25.4mm
disrance up to shaft.86mm



YHDC-030

MAX. door height,  3680mm
max,cable diam.,  4mm
max,door weight,  341kg
diam. shaft,  25.4mm
disrance up to shaft.86mm



YHDC-031

MAX. door height,  5650mm
max,cable diam.,  4mm
max,door weight,  454kg
diam. shaft,  25.4mm
disrance up to shaft. 111mm



YHDC-032

MAX. door height,  9780mm
max,cable diam.,  6.35mm
max,door weight,  890kg
diam. shaft, 25.4mm
disrance up to shaft. 127mm



YHDC-033

MAX. door height,  5650mm
max,cable diam.,  4.8mm
max,door weight,  250kg
diam. shaft,  25.4mm
disrance up to shaft. 111mm



YHDC-034

vertical lift 1372mm
horizontal lift 3048mm
max door weight 455kg
diam cable 5mm
diam shaft 25.4
diatance up to shaft axis ,111mm



YHDC-035

max. headroom, 3048 mm
max door height, 3658mm
max door weight 455kg
diam cable 5mm
diam shaft 25.4mm
diatance up to shaft axis ,127mm



YHDC-036

max. headroom, 4100mm
max door height, 5150 mm
max door weight 890kg
diam cable 6mm
diam shaft 25.4mm
diatance up to shaft axis ,152mm



YHDC-037

max door height, 3352mm
max door weight 385kg
diam cable 5mm
diam shaft 25.4mm
diatance up to shaft axis ,127mm



YHDC-038

max door height, 5486mm
max door weight 450kg
diam cable 5mm
diam shaft 25.4mm
diatance up to shaft axis ,152mm



YHDC-039

max door height, 8534mm
max door weight 1000kg
diam cable 6mm
diam shaft 25.4mm
diatance up to shaft axis ,178mm
